Product Details:
|
| Product Name: | SC APC To SC UPC Fiber Optic Patchcord | Use: | FTTH |
|---|---|---|---|
| Jacket Material: | LSZH/PVC | No.of Fiber: | 1 |
| Outer Diameter: | 2.0/3.0mm | Fiber Mode: | OM1 |
| Connector Type: | SC/APC-SC/APC | Fiber Type: | G.652D |
| Cable Length: | 1m/3m/5m/15m/50m Or Customized | Brand Name: | Weiroct/OEM |
| Wavelength: | 1260-1650nm | Quality Control: | 100% Test Before Delivery |
| High Light: | SC APC To SC UPC Fiber Optic Patch Cord,1m G652D Fiber Optic Patch Cord,2.0mm Simplex Fiber Optic Patch Cord |
||
Features:
(1) Inner: Ceramic Ferrule
| Mode | SM | MM | |
| Polish | UPC | APC | PC |
| Insertion Loss | ≤0.2dB | ≤0.3dB | ≤0.2dB |
| Return Loss | ≥55dB | ≥65dB | ≥35dB |
| Interchangeability | ≤0.2dB | ||
| Salt Spray | ≤0.1dB | ||
| Repeatability | ≤0.1dB (1000 times) | ||
| Vibration | ≤0.2dB (550Hz 1.5mm) | ||
| Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
| Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
| Apex Offset | 0μm ~ 50μm | ||
| Radius of Curvature | 7mm ~ 25mm | ||
