Product Details:
|
| Model Number: | P12MPL | Product Name: | 12C MPO To LC OM3 Ribbon Cable |
|---|---|---|---|
| Jacket Material: | PVC | Conductors: | ≥10 |
| Package: | 1Unit/bag | Storage Temperature: | 40 ~ +85 |
| Operate Temperature: | 10~ + 70 | Connector Type: | MPO To LC |
| High Light: | MPO To LC Fiber Optic Patch Cord,OM3 Fiber Optic Patch Cord,12 Core Fiber Optic Patch Cord |
||
MPO (MTP) Fanout Patch Cord is a cable attached with MPO (MTP) connector on one end and generic connectors on the other end like SC, LC, etc. The cable can be mini-core (Round) or ribbon (Flat) type. 12 fiber MPO (MTP) fanout patch cord is widely used in fiber optic network. Upon request, we can also supply 24, 48, 72, 144 fibers. Available with male or female and Available with OS2, OM1, OM2, OM3, OM4 fiber.
Features
· With 12-fiber and 24-fiber MPO/MTP connector standard
· Available in OS1/2, OM2, OM3 and OM4
· Available in FC,LC, SC, ST, MU, and MTP
· Interface polished type has PC, UPC and APC
· Available in 12 / 24 / 36 / 48 / 72 / 96 / 144-fibers
· 100% factory tested
· Discrete connectors are heat-cured and use ceramic ferrules and sleeves
· Fan-out fibers from MPO/MTP connectors into individual simplex or duplex
· Customized for length, staggering, connector type, breakout style, fiber count, and labeling fiber.
|
MPO/MTP to LC Fiber Optic Patch Cord
|
|
|||
|
Type
|
Single Mode (UPC or APC Polish)
|
Mulitmode (PC Polish)
|
||
|
Fiber Count
|
8, 12, 24 core etc.
|
8, 12, 24 core etc.
|
||
|
Fiber Type
|
G652D, G657A1, G657A2 etc.
|
OM1, OM2, OM3, OM4, OM5
|
||
|
Maximum Insertion Loss
|
Standard
|
Elite Low Loss
|
Standard
|
Elite Low Loss
|
|
≤0.75db (MPO/MTP) ; ≤0.3db (LC)
|
≤0.35db (MPO/MTP) ; ≤0.3db (LC)
|
≤0.75db (MPO/MTP) ; ≤0.3db (LC)
|
≤0.35db (MPO/MTP) ; ≤0.3db (LC)
|
|
|
Return Loss
|
≥55db(UPC); ≥60db (APC)
|
N/A
|
||
|
Working Temperature
|
-40ºC ~ 80ºC
|
-40ºC ~ 80ºC
|
||
|
Test Wavelength
|
1310nm
|
850nm
|
||
