FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector

FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector
FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector

Large Image :  FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector

Product Details:
Place of Origin: China
Brand Name: Weiroct
Certification: ISO-9001/CE/ROHS
Model Number: SC,APC
Payment & Shipping Terms:
Minimum Order Quantity: 100PCS
Price: USD
Packaging Details: 250pcs/Carton
Delivery Time: 5-7 Days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 1000PCS/DAY

FTTH FTTB FTTX Sc/Upc Sc/Apc Fiber Optic Fast Connector

Description
Model Number: SC Fiber Fast Connector Type: FTTx Solutions, Sc/upc Sc/apc
No. Of Fiber: 1 Application: FTTH FTTB FTTX Network
High Light:

FTTB Sc Upc Fiber Fast Connector

,

FTTB Sc Apc Fiber Optic Fast Connector

,

FTTB Fiber Optic Fast Connector

Sc/Upc Sc/Apc Fiber Fast Connector





Catagory
Specification
Remarks
Applicable for
2.0*3.0mm FTTH Drop Cable, 2.0mm indoor cable

Fiber mode
single mode or multi mode

operation time
S
50

insertion Loss
dB
<0.5

Insertion loss typical value
dB
<0.3
<0.2 for special reuirement
Return Loss
dB
>45
>50 for APC type
Fastening Strength of bare fiber
N
>5

Tensile Strength
N
>50

Reusable
Time
>10

Operating Temperature
-40~+85

On-line tensile strength (20N)
dB
ΔIL≤0.3

Mechanical durability(500 times)
dB
ΔIL≤0.3

Drop-off test(drop-off height 4m,once per direction, totally 3 times
dB
ΔIL≤0.3


Package
Dimension
(cm)
Weight(kgs)
100pcs/box
8*12*15
0.5
1000pcs/box
40*30*20
6
