Product Details:
|
Type: | FTTx Solutions | Usage: | FTTx FTTH FTTB Network |
---|---|---|---|
Product Name: | Fast Connector | Insertion Cycle: | More Than 1000 Times |
Dimensions: | 50mm*8.9mm*7mm | Tension: | 20N |
Return Loss:: | ≥50db | Insertion Loss: | ≤0.3db |
Working Temperature: | -40℃~80℃ | Onnector: | SC UPC/PC |
Fiber:: | 2.0*3.0 GJXH Or Customized | ||
High Light: | APC Fiber Optic Fast Connector,UPC Fiber Optic Fast Connector,UPC APC Fast SC Connector |
Lead time
Quantity(Pieces) | 1 - 10000 | 10001 - 100000 | 100001 - 500000 | >500000 |
Est. Time(days) | 3 | 7 | 15 | To be negotiated |
Features
1 . FTTH project usable
2 . Field installable
3 . Insert loss less than 0 . 3db
4 . Metal V-shape cavity work well in high and low temperature
5 . Installation less than 1 minutes
6 . Reliable and superior optical performance
7 . Cable Tensile test complies with Telcordia GR-326-COR
Optical Characteristics
Products Display
Installation
