Product Details:
|
| Connector Type: | LC/SC/ST/FC/MU/MTRJ, Etc | Wavelength: | 1260 To 1650nm |
|---|---|---|---|
| Type: | Fiber Optic Plc Splitter, 1x2 1x4 1x8 1x16 2x8 2x16 | Connector: | SC LC |
| Cable Type:: | G657A1 Or As Customers' Order | Operating Temperation: | -40℃ To 85℃ |
| No. Of Fiber: | 2 4 8 16 | Usage: | FTTH |
| Name: | 1 Input 8 Output 1x8 Steel Tube Fiber Optic Splitter With SC APC Connectors | ||
| High Light: | 1x8 Steel Tube Fiber Optic Splitter,SC APC Fiber Optic PLC Splitter,Steel Tube Fiber Optic PLC Splitter |
||
|
Parameters
|
1X4
|
1X8
|
1X16
|
1X32
|
|
Operating Wavelength (nm)
|
1260~1650
|
|||
|
Fiber Type
|
PM fiber 980,1310,1550 or customer specified
|
|||
|
Insertion Loss (dB)
|
≤7.5
|
≤10.5
|
≤13.7
|
≤16.9
|
|
Loss Uniformity (dB)
|
≤0.6
|
≤0.8
|
≤1.2
|
≤1.5
|
|
ER (dB)
|
≥20
|
≥20
|
≥18
|
≥18
|
|
Return Loss (dB)
|
≥50
|
|||
|
Operating Temperature (℃)
|
-5~+70
|
|||
|
Storage Temperature (℃)
|
-40~+85
|
|||
|
Device Dimension (mm) (L×W×H)
|
40×4×4
|
40×4×4
|
50×4×4
|
50×7×4
|
|
Module Dimension (mm) (L×W×H)
|
100x80x10
|
|||
